Case for Diagnosis
Acceso a texto completo
Indurated Plaque on the Upper Lip of a Patient With Multiple Myeloma
Placa infiltrada en labio superior de paciente con mieloma múltiple
C. Ramos-Rodrígueza,
Autor para correspondencia

Corresponding author.
, L. González-Lópeza, M. García-Arpab
a Servicio de Anatomía Patológica, Hospital General Universitario de Ciudad Real, Ciudad Real, Spain
b Servicio de Dermatología, Hospital General Universitario de Ciudad Real, Ciudad Real, Spain
Información del artículo
Texto completo
Descargar PDF
Figuras (2)
Texto completo
Clinical History

The patient was an 87-year-old woman with multiple myeloma who was receiving treatment with bendamustine and prednisone. She was seen for a lesion on her upper lip that had first appeared 2 weeks previously, coinciding with the last cycle of chemotherapy. She had previously had painful vesicles on the hard palate and tip of the tongue.

Physical Examination

Physical examination revealed an indurated erythematous-edematous plaque and crusting vesicles on the left side of the upper lip and an erythematous macule on the nasal septum and left nasal ala (Fig. 1A).

Figure 1.

B, Hematoxylin-eosin ×4. C, Hematoxylin-eosin ×10. D, Hematoxylin-eosin ×20. gr1.


Histopathology revealed an epidermis with mild acanthosis, spongiosis, and exocytosis in the absence of cytopathic changes. The follicular epithelium contained foci of vacuolar degeneration and solitary apoptotic keratinocytes. A dense lymphoplasmacytic infiltrate with noncaseating granulomas was visible in the dermis (Figs. 1B-D). Histochemistry did not reveal germs. The lymphoid infiltrate comprised predominantly CD3 cells (Figs. 2A and B), with CD30+ cells and no light chain restriction. Immunohistochemistry for herpes simplex virus (HSV) types 1 and 2 was negative. Polymerase chain reaction of the exudate for determination of HSV was negative, although it proved to be positive for HSV-1 in the biopsy specimen.

Figure 2.

A, CD3 ×4. B, CD20 ×20. gr2.


What is your diagnosis?


Atypical granulomatous herpes simplex infection.

Clinical Course and Treatment

Given the clinical suspicion of HSV infection in an immunosuppressed patient, treatment was started with famciclovir 750mg/d for 14 days. The patient's clinical condition improved, with mild residual erythema remaining.


Cutaneous eruptions caused by HSV-1, HSV-2, and varicella-zoster virus are common. Diagnosis is generally based on the presence of characteristic vesicles. All 3 viruses are histopathologically indistinguishable. The most commonly observed entities are balloon-like basal keratinocytes with multinuclear nuclei, ground glass appearance, and a vacuolated eosinophilic cytoplasm. Secondary acantholysis, epidermal necrosis, ulceration, and leukocytoclastic vasculitis are also observed.1 However, in immunosuppressed patients and patients with cancer and blood diseases in particular, lesions can also present as plaques, papules, nodules, tumors, and ulcers that tend to be chronic. In such cases, therefore, it is common practice to take biopsy specimens,2 and histology findings may be similar to those of benign and malignant lesions, with little or no epidermal involvement. Various findings have been proposed as diagnostic criteria in these patients, including involvement of adnexal structures with a vacuolar interface pattern and periadnexal infiltrate, as well as keratinocytic necrosis, multinucleation, syringotropism, and perineural symptoms.1,3,4

The lesion rarely presents as granulomatous dermatitis. In fact, in a recent review that analyzed the histopathologic characteristics of HSV, this presentation was found in only 1 out of 65 cases studied.3

Furthermore, in some series, the presence of atypical lymphocytes has been reported in more than 65% of cases. These cells can express CD30, thus mimicking CD30+ lymphoproliferative disorders.3 In rare cases, HSV infection leads to a CD56+ lymphocyte–rich infiltrate, thus mimicking NK/T lymphoma; in other cases it mimics B-cell lymphoma and plasmacytoma. Herpes infection can also mimic inflammatory conditions such as lupus, insect bites and stings, rosacea, erythema multiforme, and linear IgA bullous dermatosis. In these conditions, confirming a diagnosis requires a high degree of suspicion, and performance of immunohistochemistry testing for herpes can help, although its sensitivity is lower in the absence of vesicles, as is the case for polymerase chain reaction.4

Furthermore, there have been reports of inflammatory oncotaxis in areas affected by herpesvirus infection in patients with leukemia (especially B-cell chronic lymphocytic leukemia) and neoplastic plasma cell infiltrate in affected areas of patients with myeloma (ruled out in the present case). It was also necessary to differentiate our findings from the Wolf isotopic response, where several types of dermatosis, mainly granulomatous dermatitis, affect an area that had previously been infected by herpesvirus, mainly herpes zoster infection, but that was now healed.5 The latency period of both conditions ranges from a few weeks to years.6 The underlying mechanism of this entity could be a delayed hypersensitivity reaction, since viral DNA is not usually identified and outcome is not affected by antiviral treatment.6

Conflicts of Interest

The authors declare that they have no conflicts of interest.


We are grateful to the staff of the Histopathology Service of Hospital General Universitario de Ciudad Real for their help.

B. Hoyt, J. Bhawan.
Histological spectrum of cutaneous herpes infections.
Am J Dermatopathol, 36 (2014), pp. 609-616
N. Fujimoto, M. Wakabayashi, T. Tanaka, H. Minamiguchi, K. Hodohara.
Herpes folliculosebaceous ulcer in a patient with chronic lymphocytic leukaemia: An ulcerative variant of herpes folliculitis associated with herpesvirus invasion of folliculosebaceous units in immunocompromised hosts.
Clin Exp Dermatol, 35 (2010), pp. 447-449
B. Leinweber, H. Kerl, L. Cerroni.
Histopathologic features of cutaneous herpes virus infections (herpes simplex, herpes varicella/zoster) a broad spectrum of presentations with common pseudolymphomatous aspects.
Am J Surg Pathol, 30 (2006), pp. 50-58
A. Böer, N. Herder, N. Blödorn-Schlicht, V. Steinkraus, T.M. Falk.
Refining criteria for diagnosis of cutaneous infections caused by herpes viruses through correlation of morphology with molecular pathology.
Indian J Dermatol Venereol Leprol, 72 (2006), pp. 270-275
L. Requena, H. Kutzner, P. Escalonilla, S. Ortiz, J. Schaller, A. Rohwedder.
Cutaneous reactions at sites of herpes zoster scars: An expanded spectrum.
Br J Dermatol, 138 (1998), pp. 161-168
U. Serfling, N.S. Penneys, W.Y. Zhu, M. Sisto, C. Leonardi.
Varicella-zoster virus DNA in granulomatous skin lesions following herpes zoster.
J Cutan Pathol, 20 (1993), pp. 28-33

Please cite this article as: Ramos-Rodríguez C, González-López L, García-Arpa M. Placa infiltrada en labio superior de paciente con mieloma múltiple. Actas Dermosifiliogr. 2017;108:61–62.

Copyright © 2016. Elsevier España, S.L.U. and AEDV
